Granberg Countertop Lift System | Floor Mounted | Accessible Home Solution

Granberg Countertop Lift System | Floor Mounted | Accessible Home Solution

Lift Width
Planning Width

Contact form

View full details
Countertop Lift System | Home Accessibility Solutions | Accessible Home Solution

BASELIFT 6300 / 6310 is a worktop lift with great flexibility to be adapted for different needs.

The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.

The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.

The equipment in the work surface is selected according to the function desired. Sink unit, hob, drawers, chopping boards and other accessories can be integrated in the work surface.

Specification:

Installation Floor-mounted
Front height 1.57" (103 mm)
Height adjustment

Motorised, steplessly adjustable 11.8" (300 mm), 27.6"-39.4" (700-1000 mm) excl. top board

Speed level 1.2" (30 mm) / sec.
Operation Recessed mounted button
Safety

The safety strip is placed under the front edge of the worktop.
If anything touches the safety strip, the lifting unit stops

Electrical connection Plug for 110 V, max 10A
Plumbing connections Connection is made with flexible hoses
Lifting force 220 lb (100 kg)
IP-class IP 20
Frame depth 22.0"- 23.2" (560-590 mm)
Dimensions cover plates

2 pcs, width = width of the lift -0.394" (-10 mm), height 17.24" (438 mm),
thickness 0.472"-0.787" (12-20 mm)

Width worktop Width = width of the lift
Depth worktop 0.59" (15 mm) shallower than worktops on fixed cabinets
Space to wall / adjoining cabinet 0.197" (5 mm)
Space to wall (for tiles) 0.59" (15 mm)
Tiling From 27.56" (700 mm) above floor (alternatively all the way down to the floor)
Delivery modules

Ready-mounted worktop incl. safety switch, motors

Fittings supplied Bracket for fronts
Material

Aluminium frame

Warranty 3 years warranty
Granberg makes a commitment to remedy material and manufacturing defects for a period of three years from the invoicing date.
Dimensions
Dimensions - Countertop lift system Baselift 6310LA -Floor-mounted, 1.57
Dimensions - Countertop lift system Baselift 6310LA -Floor-mounted, 1.57
Dimensions - Countertop lift system Baselift 6310LA -Floor-mounted, 1.57

Functions and Advantages



  • Can be equipped with hob
  • 11.8" (30 cm) height adjustment
  • Adjustable depth, 22.0"- 23.2" (560-590 mm) from wall
  • Frame in aluminium. Prepared from factory. Movable (sideward) and angle adjustable consoles.
  • Electronic and motor system "Plug and Play"
  • Safety strip covers the front edge under the worktop. (Installed from factory)
  • Brackets and screws for installation of fronts and top board are included in the delivery

Useful information

  • The top board’s depth must be 0.6" (15 mm) shallower than adjoining top boards (to provide a gap for tiles and movement)
  • Width of the top board = width of the lift
  • Sink bowls with a maximum height of 4.7" (120 mm) can be integrated (not 6300L/6310L)
  • Electronics and motor system "Plug and Play"
  • Width of front = width of lift -0.2" (-4 mm)
    Height of front:6300H/6310H = 4.1" (103 mm), 6300L/6310L = 1.6" (40 mm). Fittings enclosed
  • Cover panels can hide installations under the worktop 2 pcs width = width of lift -0.4" (-10 mm), height 17.2" (438 mm), thickness 0.5"-0.8" (12-20 mm).

Standard equipment

  • Factory-mounted aluminium system with movable and tiltable brackets
  • Floor-mounted motors
  • Safety switch

How to Choose the Right Countertop Lift System

Choosing the right countertop lift system can be challenging, especially if you are not familiar with the different types and features available. Here are some factors to consider when choosing a countertop lift system:

1. Weight Capacity

Make sure the countertop lift system you choose can handle the weight of your countertop and any items you plan to put on it. Check the weight capacity of the lift system before making a purchase.

2. Size and Shape

Countertop lift systems come in different sizes and shapes. Make sure you choose a lift system that fits your countertop perfectly and is compatible with your existing kitchen or workspace.

3. Motor Noise

Some lift systems can be noisy, which can be distracting and annoying. Make sure you choose a lift system that operates quietly, allowing you to work or perform tasks without any disturbance.

Here comes the Beselift 6300/6310 Countertop lift system. The lift motors are designed to be continuously adjustable, allowing the work surface to be moved quickly and quietly to the desired height. Additionally, the lift system is equipped with a reliable safety mechanism that ensures safe operation without the risk of crushing.

Conclusion

Back pain is a common issue that affects millions of people worldwide. Using a countertop lift system can help you say goodbye to back pain, improve your posture, increase productivity, and promote better health. When choosing a countertop lift system, consider factors such as weight capacity, size and shape, and motor noise to ensure you get the best product for your needs.
