Height Adjustable Kitchen Island Centerlift 6490

CENTERLIFT 6490 is a motorized kitchen island.

With cabinets on one side and open space on the other side, a height-adjustable work area is created with space for knees on one side and generous storage space on the other. CENTERLIFT creates a kitchen in which everyone can work comfortably while also providing a natural place for people to gather in the kitchen on all occasions. The lifting system can be integrated with kitchens from any kitchen manufacturer.

Specification:

Installation Floor-mounted
Height adjustment

Motorised, steplessly adjustable 15.7" (400 mm)
27.6"-43.3" (700-1100 mm) excl. top board

Speed level 0.8" (20 mm) / sec.
Operation Recessed mounted buttons located in the motor units (left and right side)
Safety

Safety switches under the cabinet and under the front of spaces for knees. The function of the safety switch is to stop the
movement if it comes in contact with any object.

Electrical connection 2 Plugs for 110 V
Plumbing connections Connection is made with flexible hoses
Lifting force 880 lb (400 kg)
IP-class IP 20
Frame depth 43.5" (1106 mm)
Front height - open side 4.06" (103 mm)
Dimensions cover plates - open side 1 pc, width = width of lift, height 20.0" (510 mm), thickness 0.5"-0.8" (12-20 mm)
Width worktop Width of lift + thickness of the side cover + Desired protrusion
Depth worktop Depth of lift, 43.5" (1106 mm) + thickness of the front cover + Desired protrusion
Delivery modules

1 package with motor units. 1 package with length-dependent beams. 1 package with ready-mounted aluminium system for the part with space for knees

Fittings supplied Bracket for fronts and top board
Material

Motor units in lacquered steel (S235JRG2). Aluminium beams Aluminium frame for the part with space for knees

Warranty 3 years warranty
Granberg makes a commitment to remedy material and manufacturing defects for a period of three years from the invoicing date.
Dimensions
Dimensions - Height Adjustable Kitchen Island Centerlift 6490
Dimensions - Height Adjustable Kitchen Island Centerlift 6490
Dimensions - Height Adjustable Kitchen Island Centerlift 6490

Functions and Advantages

  • Motorised kitchen island lift for cabinets and the part with space for knees
  • Height-adjustable 27.5"- 43.3" above floor (excl. top board)
  • 880 lb (400 kg) lifting power
  • Safety switch under storage cabinet and the part with space for knees.

Useful information

  • Fittings for worktop and fronts are included
  • Worktop width = lift width + thickness of side cover + desired protrusion
  • Worktop depth = lift depth (1106 mm) + thickness of front cover + desired protrusion
  • Electronics and motor system "Plug and Play"
  • Cover panel can hide installations under the worktop on the side with space for knees 1 pc, width = width of lift, height 20.0" (510 mm), thickness 0.5"-0.8" (12-20 mm)

Standard equipment

- Factory-mounted aluminium system
- Floor-mounted motors
- Control button
- Safety switch at the part with space for knees
