Accessible Home Solution

Granberg Kitchen Countertop Baselift 6303/6313 - 90º Corner | Accessible Home Solutions

Granberg Kitchen Countertop Baselift 6303/6313 - 90º Corner | Accessible Home Solutions

Contact form

View full details

Description:



BASELIFT CORNER is a wall- or floor mounted worktop lift with great flexibility to be adapted for different needs.

The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.

The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.

Specification:

Installation Wall or Floor -mounted
Front height 4.06" (103 mm)
Corner solution 90° front edge, 90° wall
Height adjustment

Motorised, steplessly adjustable 11.8" (300 mm), 27.6"-39.4" (700-1000 mm) excl. top board)

Speed level 1.2" (30 mm) / sec.
Operation Recessed mounted button
Safety

The safety strip is placed under the front edge of the worktop.
If anything touches the safety strip, the lifting unit stops.

Electrical connection 2 Plugs for 110 V
Plumbing connections Connection is made with flexible hoses
Lifting force 100 kg
IP-class IP 20
Frame depth Adjustable depth, 22.0" - 23.2" (560 – 590 mm) from wall
Dimensions cover plates

2 pcs, height 17.2" (438 mm), thickness 0.5"-0.8" (12-20 mm)

Width worktop Width = width of the lift
Depth worktop 0.6" (15 mm) shallower than worktops on fixed cabinets
Space to wall / adjoining cabinet 0.2" (5 mm)
Space to wall (for tiles) 0.6" (15 mm)
Tiling From 27.6" (700 mm) above floor (alternatively all the way down to the floor)
Delivery modules

Ready-mounted worktop incl. safety switch, motors

Fittings supplied Bracket for fronts and top board
Material

Aluminium frame

Warranty 3 years warranty
Granberg makes a commitment to remedy material and manufacturing defects for a period of three years from the invoicing date.
Dimensions
Dimensions - Countertop lift system Baselift Corner 6303H, 90°- 90°, wall-mounted
Dimensions - Countertop lift system Baselift Corner 6303H, 90°- 90°, wall-mounted
Dimensions - Countertop lift system Baselift Corner 6303H, 90°- 90°, wall-mounted

23.43" x 23.43" (59.5 x 59.5 cm)
90° front edge, 90° wall

 Functions and Advantages

  • Can be equipped with drawers, hob and sink
  • 11.8" height adjustment
  • Adjustable depth, 22.0" - 23.2" from wall
  • Frame in aluminium. Prepared from factory. Movable (sideward) and angle adjustable consoles.
  • Electronic and motor system "Plug and Play"
  • Safety strip covers the front edge under the worktop. (Installed from factory)
  • Brackets and screws for installation of fronts and top board are included in the delivery

How to Choose the Right Countertop Lift System

Selecting the right countertop lift system can be a daunting task. Here are a few considerations to help you make an informed decision:

  • Evaluate your needs: Determine your specific requirements, such as the intended use, desired features, and budget. This will help you narrow down the options and find a countertop lift system that aligns with your needs.

  • Research reputable brands: Look for well-established brands that have a track record of producing high-quality countertop lift systems. Read customer reviews and ratings to get insights into the performance and reliability of different brands.

  • Consider design and aesthetics: Countertop lift systems come in various designs and finishes. Choose a system that complements the overall style of your space and enhances its visual appeal.

  • Check installation requirements: Ensure that the countertop lift system you choose is compatible with your existing space. Consider factors such as available electrical connections, structural support, and any necessary modifications.

  • Assess warranty and customer support: Look for a countertop lift system that comes with a warranty or guarantee. Additionally, consider the availability of customer support and after-sales service to address any potential issues or concerns.

Popular Countertop Lift System Brands

When choosing a countertop lift system, it's helpful to be aware of reputable brands that offer reliable products. Here are three popular brands known for their quality and innovation:

1. Accessible Home Solution

Accessible Home Solution is renowned for its cutting-edge technology and sleek designs. Their countertop lift systems are known for their smooth operation and durability, making them a popular choice among homeowners and professionals alike.

2. Granberg

Granberg focuses on versatility and customization. They offer a wide range of options, allowing customers to personalize their countertop lift system according to their style preferences and functional requirements.
